Network Enumeration with Nmap - Cheat Sheet

SYNTAX

nmap <scan types> <options> <target>

Host Discover

Command	Description
-sn	Disable port scanning. Host discovery only.
-PE	Performs the ping scan by using ICMP Echo Requests against the target
nmap -sn 10.129.2.12	Scan Single IP
nmap -sn 10.129.2.0/24	Scan Network range
nmap -sn -iL hosts.lst	Scan IP List
nmap -sn 10.129.2.12 10.129.2.13 10.129.2.17	Scnan Multiple IPs
nmap -sn 10.129.2.12-18	Scan Multiple IPs

Port Scanning

Command	Description
-sS	Syn Scan
-sT	TCP Scan
-sU	UDP Scan
--top-ports=10	Scans the specified top ports that have been defined as most frequent.
-F	Fast Scan. Scans top 100 Ports
-Pn	Treat all hosts as online – skip host discovery
-p 80	Only scan Port 80
-p 80,8080	scan Ports 80 and 8080
-p 80-90	Scan port range
-p-	Scan all ports

Saving The Results

Command	Description
-oN	Normal output with the .nmap file extension
-oG	Grepable output with the .gnmap file extension
-oX	XML output with the .xml file extension
-oA Target	Saves the results in all formats, starting the name of each file with Target.

Service and OS Enumeration

Command	Description
-O	OS Detection
-sV	Service version enumeration
-A	Agressive Scanning. Enables OS detection (-O), version detection (-sV), script scanning (-sC), and traceroute (–tracerout)

Nmap Scripting Engine (NSE)

Command	Description
-sC	default NSE scripts. Equivalent to –script=default
--script <category>	Use specific Scripy category
--script <scripy_Name>,<script_Name>	Use defined scripts

Script Categories

Script Category	Description
auth	Determination of authentication credentials.
broadcast	Scripts, which are used for host discovery by broadcasting and the discovered hosts, can be automatically added to the remaining scans.
brute	Executes scripts that try to log in to the respective service by brute-forcing with credentials.
default	Default scripts executed by using the -sC option.
discovery	Evaluation of accessible services.
dos	These scripts are used to check services for denial of service vulnerabilities and are used less as it harms the services.
exploit	This category of scripts tries to exploit known vulnerabilities for the scanned port.
external	Scripts that use external services for further processing.
fuzzer	This uses scripts to identify vulnerabilities and unexpected packet handling by sending different fields, which can take much time.
intrusive	Intrusive scripts that could negatively affect the target system.
malware	Checks if some malware infects the target system.
safe	Defensive scripts that do not perform intrusive and destructive access.
version	Extension for service detection.
vuln	Identification of specific vulnerabilities.

Performance

• rtt → Round trip Time → Time receive a response from the scanned port.

• Default value for the retry rate is 10.

Command	Description
--min-rtt-timeout 100ms	Sets the specified time value as Min RTT timeout.
--max-rtt-timeout 100ms	Sets the specified time value as Max RTT timeout
--initial-rtt-timeout 50ms	Sets the specified time value as initial RTT timeout.
--max-retries 0	Sets the number of retries that will be performed during the scan.
--min-rate 300	Sets the minimum number of packets to be sent per second.
-T <0-5>	Time template to use

Time Template

Source here

Firewall and IDS/IPS Evasion

Command	Description
nmap 192.168.1.1 -D 192.168.1.35, 192.168.1.26, 192.168.1.13, 192.168.1.100	Decoys. Send scans from spoofed IPs
-D RND:5	Generate five random IPs that indicates the source IP the connection comes from
-S <IP>	Scans the target by using different source IP address.
-e tun0	Sends all requests through the specified interface.
--source-port <Port Number>	Perform the scans from the specified source port

Mission Complete
